Opis
Tehnične specifikacije
| Okvir |
All New Series 4 Alloy Frame, 150mm Multitrac suspension, Integrated Battery/On-switch/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor |
| Sprednje vilice | Fox 38 Performance Elite, 160mm travel, 29" , 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender |
| Zadne vzmetenje |
Fox Float DHX2, Performance Elite, Low Speed Compression and Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 25mmxM8 Lower Mount, S/M Spring = 350lb, L/XL Spring = 450lb |
| Obroči |
Front: Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width; Rear: Marin Aluminum Double Wall, 27.5" Diameter, 38mm Inner Rim Width; Pinned Joint, Disc Specific, Tubeless Compatible |
| Zadnja pesta |
Shimano HB-MT510B, 148x12mm, Centerlock, Microspline Freehub Body |
| Prednja pesta |
Shimano MT-410B, 110x15mm, Centerlock Disc, 32H |
| Napere |
14g Black Stainless Steel |
| Plašči |
Front: Vee Tire Co Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Rear: Vee Tire Co Crown Gem, 27.5x2.8”, TACKEE Compound, Tubeless Compatible |
| Zadnji menjalnik |
Shimano XT 8100 12-Speed, SGS |
| Prednji menjalnik | - |
| Prestavne ročice |
Shimano SLX 7100 12-Speed, I-Spec EV |
| Gonilke |
e13 e*Spec Plus Crank, 165mm Length with e13 e*Spec DM Chainring 38T, e13 Plus Chainguide, Aluminum Plate |
| Motor |
Shimano Steps EP8 Drive Unit, 250W, 85Nm |
| Baterija | BT-8036, Internal 630Wh |
| Zaslon | SC-E8000 Display |
| Switch | SW-E7000 Left Hand Switch for Assist Mode Change |
| Veriga |
KMC E12S, EBike Specific Chain |
| Verižnik | Shimano SLX M7100, 12-Speed, 10-51T |
| Prednje zavore |
Shimano SLX 4-Piston Hydraulic Disc, 203mm Rotor |
| Zadnje zavore | Shimano SLX 4-Piston Hydraulic Disc, 203mm Rotor w/ Speed Sensor |
| Zavorne ročice |
Shimano SLX Levers, I-Spec EV |
| Krmilo | Marin 35mm 7000 Alloy Bar, 780mm Length, 5 Degree Up, 8 Degree Back |
| Nosilec krmila |
Marin CNC Stem, 35mm Length, 35mm Bar Bore |
| Grips |
Marin Single Clamp Locking |
| Krmilni ležaj |
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| Sedežna opora |
X-Fusion Manic, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm |
| Sedež |
Marin eMTB Saddle |
| Pedala | - |
